| UCP series |
ˇˇˇˇPillow Blocks are composed of two-sealed
outer ball bearing and a casting bearing block. The inner of outside
ball bearing is the same with deep grove bearing, but the outer
race has the cross-sectional ball surface, which can regulate
the center automatically in combination with concave ball surface
of the bearing block. In general, there exist the interspaces
between the inner bore and the shaft. The eccentric sleeve and
adapter sleeve fix the bearing inner race on the shaft, and also
start with the shaft. The insert bearings feature the characteristics
of compact conformation, convenient setup, which suits for the
simple supporting, and also widely used in the fields of mining,
metallurgy, agriculture, chemical, and conveying machinery.
|
 |
|
| Bearing No. |
|
in |
h |
a |
e |
b |
S1 |
Bi |
n |
g |
|
UCP203
UCP203-11 |
17
17.4625 |
11/16 |
30.2
30.2 |
127
127 |
95
96 |
38
38 |
13
13 |
31.0
31.0 |
12.7
12.7 |
15
15 |
|
UCP204-12
UCP204 |
19.0500
20 |
3/4
|
33.3
33.3 |
127
127 |
96
95 |
38
38 |
13
13 |
31.0
31.0 |
12.7
12.7 |
15
15 |
|
UCP205-14
UCP205-15
UCP205
UCP205-16 |
22.2250
23.8125
25
25.4000 |
7/8
15/16
1 |
36.5
36.5
36.5
36.5 |
140
140
140
140 |
105
105
105
105 |
38
38
38
38 |
13
13
13
13 |
34.0
34.0
34.1
34.0 |
14.3
14.3
14.3
14.3 |
16
16
16
16 |
|
| UCP206-17
UCP206-18
UCP206
UCP206-19
UCP206-20 |
26.9875
28.5750
30
30.1625
31.7500 |
1-1/16
1-1/8
1-3/16
1-1/4 |
42.9
42.9
42.9
42.9
42.9 |
160
160
165
160
160 |
121
121
121
121
121 |
48
48
48
48
48 |
17
17
17
17
17 |
38.1
38.1
38.1
38.1
38.1 |
15.9
15.9
15.9
15.9
15.9 |
18
18
17
18
18 |
|
UCP207-20
UCP207-21
UCP20- 22
UCP207
UCP207-23 |
31.7500
33.3375
34.9250
35
36.5125 |
1-1/4
1-5/16
1-3/8
1-7/16 |
47.6
47.6
47.6
47.6
47.6 |
167
167
167
167
167 |
126
126
126
127
126 |
48
48
48
48
48 |
17
17
17
17
17 |
42.9
42.9
42.9
42.9
42.9 |
17.5
17.5
17.5
17.5
17.5 |
19
19
19
19
19 |
|
UCP208-24
UCP208-25
UCP208 |
38.1000
39.6875
40 |
1-1/2
1-9/16
|
49.2
49.2
49.2 |
180
180
184 |
136
136
137 |
54
54
54 |
17
17
17 |
49.2
49.2
49.2 |
19.0
19.0
19.0 |
19
19
19 |
|
UCP209-26
UCP209-27
UCP209-28
UCP209 |
41.2750
42.8625
44.4500
45 |
1-5/8
1-11/16
1-3/4
|
54.0
54.0
54.0
54.0 |
190
190
190
190 |
146
146
146
146 |
54
54
54
54 |
17
17
17
17 |
49.2
49.2
49.2
49.2 |
19.0
19.0
19.0
19.0 |
20
20
20
20 |
|
UCP210-30
UCP210-31
UCP210
UCP210-32 |
47.6250
49.2125
50
50.8000 |
1-7/8
1-15/16
2 |
57.2
57.2
57.2
57.2 |
206
206
206
206 |
159
159
159
159 |
60
60
60
60 |
20
20
20
20 |
51.6
51.6
51.6
51.6 |
19.0
19.0
19.0
19.0 |
22
22
22
22 |
|
|
UCP211-32
UCP211-34
UCP211
UCP211-35 |
50.8000
53.9750
55
55.5625 |
2
2-1/8
2-3/16 |
63.5
63.5
63.5
63.5 |
219
219
219
219 |
172
172
171
172 |
60
60
60
60 |
20
20
20
20 |
55.6
55.6
55.6
55.6 |
22.2
22.2
22.2
22.2 |
22
22
22
22 |
|
|
| |
| Bearing No. |
|
in |
h |
a |
e |
b |
S1 |
Bi |
n |
g |
|
UCP212-36
UCP212-37
UCP212
UCP212-38
UCP212-39 |
57.1500
58.7375
60
60.3250
61.9125 |
2-1/4
2-5/16
2-3/8
2-2/16 |
69.9
69.9
69.8
69.9
69.9 |
241
241
241
241
241 |
186
186
184
186
186 |
70
70
70
70
70 |
20
20
20
20
20 |
65.1
65.1
65.1
65.1
65.1 |
25.4
25.4
25.4
25.4
25.4 |
25
25
25
25
25 |
|
UCP213-40
UCP213
UCP213-43 |
63.5000
65
68.2625 |
2-1/2
2-11/16 |
76.2
76.2
76.2 |
265
265
265 |
203
203
203 |
70
70
70 |
25
25
25 |
65.1
65.1
65.1 |
25.4
25.4
25.4 |
27
27
27 |
|
UCP214-44
UCP214 |
69.8500
70 |
2-3/4
|
79.4
79.4 |
266
266 |
210
210 |
72
72 |
25
25 |
74.6
74.6 |
30.2
30.2 |
27
27 |
|
UCP215-44
UCP215-47
UCP215
UCP215-48 |
69.8500
74.6125
75
76.2000 |
2-3/4
2-15/16
3 |
82.6
82.6
82.6
82.6 |
275
275
275
275 |
217
217
217
217 |
74
74
74
74 |
25
25
25
25 |
77.8
77.8
77.8
77.8 |
33.3
33.3
33.3
33.3 |
28
28
28
28 |
|
UCP216-50
UCP216
UCP216-52 |
79.3750
80
82.5500 |
3-1/8
3-1/4 |
88.9
88.9
88.9 |
292
292
292 |
232
232
232 |
78
78
78 |
25
25
25 |
82.6
82.6
82.6 |
33.3
33.3
33.3 |
30
30
30 |
|
UCP217-52
UCP217 |
82.5500
85 |
3-1/4
|
95.2
95.2 |
310
310 |
247
247 |
83
83 |
25
25 |
85.7
85.7 |
34.1
34.1 |
32
32 |
|
UCP218-56
UCP218 |
88.9000
90 |
3-1/2
|
101.6
101.6 |
327
327 |
262
262 |
88
88 |
27
27 |
96.0
96.0 |
39.7
39.7 |
34
34 |
|
UCP305-14
UCP305-15
UCP305
UCP305-16 |
22.2250
23.8125
25
25.4000 |
7/8
15/16
1 |
45
45
45
45 |
175
175
175
175 |
132
132
132
132 |
45
45
45
45 |
17
17
17
17 |
38.0
38.0
38.0
38.0 |
15
15
15
15 |
16
16
16
16 |
|
|
UCP306-18
UCP306
UCP306-19 |
28.5750
30
30.1625 |
1-1/8
1-3/16 |
50
50
50 |
180
180
180 |
140
140
140 |
50
50
50 |
17
17
17 |
43.0
43.0
43.0 |
17
17
17 |
18
19
18 |
|
UCP307-20
UCP307-21
UCP307-22
UCP307
UCP307-23 |
31.7500
33.3375
34.9250
35
36.5125 |
1-1/4
1-5/16
1-3/8
1-7/16 |
56
56
56
56
56 |
210
210
210
210
210 |
160
160
160
160
160 |
56
56
56
56
56 |
17
17
17
17
17 |
48.0
48.0
48.0
48.0
48.0 |
19
19
19
19
19 |
20
20
20
21
20 |
|
UCP308-24
UCP308-25
UCP308 |
38.1000
39.6875
40 |
1-1/2
1-9/16
|
60
60
60 |
220
220
220 |
170
170
170 |
60
60
60 |
17
17
17 |
52
52
52 |
19
19
19 |
22
22
23 |
|
|
|
|
UCP309-24
UCP309-27
UCP309-28
UCP309 |
41.2750
42.8625
44.4500
45 |
1-5/8
1-11/16
1-3/4
|
67
67
67
67 |
245
245
245
245 |
190
190
190
190 |
67
67
67
67 |
20
20
20
20 |
57
57
57
57 |
22
22
22
22 |
24
24
24
25 |
|
|
| |
| Bearing No. |
|
in |
h |
a |
e |
b |
S1 |
Bi |
n |
g |
|
|
UCP310-30
UCP310-31
UCP310 |
47.6250
69.2125
50 |
1-7/8
1-15/16
|
75
75
75 |
275
275
275 |
212
212
212 |
75
75
75 |
20
20
20 |
61
61
61 |
22
22
22 |
27
27
28 |
|
|
UCP311-32
UCP311-34
UCP311
UCP311-35 |
50.8000
53.9750
55
55.5625 |
2
2-1/8
2-3/16 |
80
80
80
80 |
310
310
310
310 |
236
236
236
236 |
80
80
80
80 |
20
20
20
20 |
66
66
66
66 |
25
25
25
25 |
30
30
31
30 |
|
UCP312-36
UCP312
UCP312-38
UCP312-39 |
57.1500
60
60.3250
61.9125 |
2-1/4
2-3/8
2-2/16 |
85
85
85
85 |
330
330
330
330 |
250
250
250
250 |
85
85
85
85 |
25
25
25
25 |
71
71
71
71 |
26
26
26
26 |
32
33
32
32 |
|
UCP313-40
UCP313 |
63.5000
65 |
2-1/2
|
90
90 |
340
340 |
260
260 |
90
90 |
25
25 |
75
75 |
30
30 |
35
36 |
|
UCP314-44
UCP314 |
69.8500
70 |
2-3/4
|
95
95 |
360
360 |
280
280 |
90
90 |
27
27 |
78
78 |
33
33 |
35
40 |
|
UCP315
UCP315-48 |
75
76.2000 |
3 |
100
100 |
380
380 |
290
290 |
100
100 |
27
27 |
82
82 |
32
32 |
40
35 |
|
UCP316-50
UCP316 |
79.3750
80 |
3-1/8
|
106
106 |
400
400 |
300
300 |
110
110 |
27
27 |
86
86 |
34
34 |
40
45 |
|
UCP317-52
UCP317 |
82.5500
85 |
3-1/4
|
112
112 |
420
420 |
320
320 |
110
110 |
33
33 |
96
96 |
40
40 |
40
40 |
|
|
UCP318-56
UCP318 |
88.9000
90 |
3-1/2
|
118
118 |
430
430 |
330
330 |
110
110 |
33
33 |
96
96 |
40
40 |
45
50 |
|
|
| |
|
|
